FB575 digital flatbed cutter
FB575 digital flatbed cutter
This is a high-specification B3 cutting device with a compact footprint. The cutting table accommodates up to one SRA3 (Tabloid Plus) sheet and is targeted for light production work.
Description
Additional Information
Size Chart
Cut area:
Max media area: 350mm x 520mm
Effective cutting area: 330mm x 488mm
Stand: included
Media hold down method: 400W vacuum suction
Acoustic cover for pump: yes
Silencer: optional
Cutting force: Tool 1: Cut – up to 960gf (0.96Kg) / Tool 2: Crease up to 960gf (0.96Kg)
Max cutting depth: Paper/card up to 600 micron/600gsm, Max. depth 1mm (low density substrate ie. Foamboard), High Density Substrates: PVC – up to 0.4mm, PET – up to 0.3mm, magnetic sticker – up to 600µ
Max speed: 600mm/s.
Typical cut accuracy: +/- 125 μ
Mountable tools: 3 tools supplied as standard for either tool position: blade holder, creasing tool (double ended) & pen tool for calibration
Software connectivity
ColorCut Pro – (Plug-in) ColorCut Pro Client (supplied) is a plugin for Adobe® Illustrator® (Mac or PC) & CorelDRAW® (PC only) (requires either app). Automatically adds cut registration targets (PageMARKs), BarCodes/QR Codes and Job numbers to the cut files. Then creates the cut files and sends cut files to the ColorCut Pro Job library.
ColorCut Pro – (Production Studio): PC only. Windows 10 Pro x64 bit, 4 GB of RAM. Recommended Resolution: 1280×960 or higher. Wi-Fi for Live Video (Wi-Fi Dongle inc. with cutter). 1 x USB.
Registration control:
Registration system: IR optical sensor reads Bar Codes for instant job retrieval, also accurately reads registration marks, corrects linear, scale, skew and rotational/angular positional differences adapting the cut file as required.
General
Weight: 69kg unpacked.
Max’ dimensions: 900 x 870 x 1020mm unpacked.
