FB9000 PRO

The ColorCut FB9000 PRO represents a pinnacle in automated digital die flatbed cutting and creasing technology offered by Elite International Sales of Printing Machinery Co. This cutting-edge machine is engineered to revolutionize production efficiency and precision in the printing industry.


Additional Information

Size Chart

Max media area:
(auto sheet feed) 480mm x 720mm
(manual placement) 550mm x 850mm (no mark scanning)

Effective cutting area:
(auto sheet feed) 480mm x 720mm
(manual placement) 495mm x 735mm

Registration system:
High-speed CCD Camera – Vision3 Registration System, using live video feed and advanced 8th generation ARMS (Automatic Registration Mark System)

Job recognition:
Advanced QR code technology for instant file recognition and registration

Stand: integral and included

Media hold down method: 2 zone vacuum bed (High speed 750W vacuum pump included as standard)

Acoustic cover for pump: yes

Acoustic features: Acoustic cover/housing for vacuum pump, silencer for vacuum pump intake


Mountable tools: dual tool functionality, so any 2 tools can be fitted simultaneously – 3 tools supplied as standard: Blade holder, creasing tool & pen calibration tool

Cutting force: Up to 1.2kg
Creasing force: Up to 1.5kg


Uncrated: Length: 1,000mm (39.37″) Width: 2,500mm (98.42″) Depth: 1,600mm (62.99″)
