FB1180T tangential digital flatbed cutter

Introducing the New Generation FB1180T B1+ Tangential Digital Flatbed Cutter from Elite International Sales of Printing Machinery Co. This cutting-edge machine embodies innovation and precision in the realm of digital flatbed cutting technology.


Additional Information

Size Chart

Cut area:

Format/size: B1+ (4 x SRA3) / US ARCH E1 (4 x Tabloid Extra)
Maximum media area: 800mm x 1100mm
Effective contour cutting area: 680mm x 1020mm
Stand: Included
Media hold-down method: 1100W vacuum suction
Acoustic Muffler / Silencer: included

Cutting control:

Cutting carriage: Quad Tool Cutting Carriage, 4 Tool positions
Cutting force: up to 2,500gf (2.5)
Crease force: up to 2,500gf (2.5)
Max cutting depth: Paper/card up to 1000micron/800gsm, Max. depth 1.2mm (low density substrate ie. rice paper / airboard). 3000 micron on E/F/N Fluted board and selected media up to 3mm
Max speed:* High Quality: 750mm/s. Standard Mode: 960mm/s. Fast Mode: 1,200mm/s
Typical cut accuracy: +/- 125 μ
Mountable tools: 5 tools supplied as standard: Blade holder, creasing tool & pen tool, tangential wheel creaser, tangential blade cutter

Software connectivity

ColorCut Pro – Production Studio 5: Windows 10 Pro x64 bit, 4 GB of RAM. Recommended Resolution: 1280×960 or higher.. Wi-Fi for Live Video (Wi-Fi Dongle inc. with cutter). 1 x USB or 1 x Ethernet.
Registration control:
Registration system: Advanced 8th generation ARMS (Automatic Registration Mark System), Uses hi-res CCD camera system to read QR codes for instant job retrieval, also accurately reads registration marks, corrects linear, scale, skew and rotational/angular positional differences adapting the the cut file as required.


Weight: 100kg unpacked.
Max’ dimensions: 1550 x 1350 x 1098mm
