GeminiCut Air 331BSC

Achieve slit, cut, crease, or perforation in a single pass with the 331BSC.


Additional Information

Size Chart

Infeed size: 210*210mm-330*650mm
Outfeed size: 55*48mm-330*650
Paper weight:  150-350gsm
Paper type: Chrome, laminated,UV coated etc.
Crease width: 1.0mm
Perforate TPI: 12TPI
Crease/Perf in one pass: Up to 32 times in one pass
Shrink/stretch compensation: Feeding direction
Slitting: 4 slitters,2 side trimmer 2 gutter slitter with fixed 8mm (3/8 inch) gap.
Cutting: Up to 32 times in one pass
Accuracy: +/-0.2mm
Gutter slit: 8mm(3/8 inch) Fixed
Gutter cut: 0 or 3-15mm Programmable
Feeding type: Top air suction feed
Feeding capacity: 50mm
Control Panel: Touch screen
Power: Either 220V Or 110V ,50Hz/60Hz
