PSCC31
PSCC31
Laminate,Slit,Cut,Corner round
Description
Additional Information
Size Chart
Film: PET roll film
Film thickness 75-125um
Max Roll dia.: 125mm
Film width: 110-335mm
Film holder width: Auto set
Heat roller pressure: Manual set
Slitter qty: 2
Infeed size: 89*127mm-320*500mm (W*L)
Max Outfeed size: 330*520mm (W*L)
Min Outfeed size: 95*133mm(Encapsulation)/83*121mm(Flush Cut)
Paper weight: 80-300gsm (Depends on film thickness)
Loading capacity: 70mm
Speed: 0.5-2m/min
Accuracy: +/-0.4mm
Corner cutter radius: R4
Corner cutter qty: 4
Skew adjustment: Manual
Warmup time: 5-15min
Memory: 20 jobs
Voltage: 220V/110V 50-60HZ
