ColorFlare CF350
ColorFlare CF350
DESKTOP MODEL - Foiling machine
Foiling, lamination and flaring effects are possible with this single desktop solution. Offering class-leading affordability, the CF350 uses 3″ (77mm) core rolls providing a more cost effective production solution. This simple in-house process requires no expensive blocks or dies.
Foiling, lamination and flaring effects are possible with this single desktop solution. Offering class-leading affordability, the CF350 uses 3″ (77mm) core rolls providing a more cost effective production solution. This simple in-house process requires no expensive blocks or dies.
Description
Additional Information
Size Chart
Laminating speed: 1.3m/min
Base substrate thickness: Lamination: 80gsm to 350gsm
Foiling: 120gsm to 350gsm
Paper Size: Maximum: 330mm to 500mm
Minimum: 180mm x 230mm
Warm-up time: 5 minutes
Heating system: Infrared heater
Laminating temperature: Top roller: maximum150°C
Bottom roller: maximum 100°C
Temperature control: Control panel push button
Speed control: Control panel push button
Display system: LCD display
Roller pressure: Adjustable manual handle
Film core size: 77mm (3″)
Air cooling system: Dual fan system
Temperature sensing method: Internal thermo-couple
Rear trimming knife: Blade for end of job trimming
Power requirement: AC 220~240V, 50/60Hz, 7A
Power consumption: 1.5kw
Dimensions (WxLxH): 580 x 500 x 430mm
Weight: 35kg
