LC 600 Automated sheet label cutting

Digitally cut any shape labels at up to 960mm/sec. Digital process means no more costly dies. QR code/Job Library retrieves associated cut files – even for mixed job batch sessions.



Additional Information

Size Chart

Media Handling: Supports a range of standard sheet sizes: A4, A3, SRA3, A3+ and custom

Custom sized label media:
Media width (min-max) 150mm – 330mm
Media length (min-max) 190mm – 750mm
Media thickness: 0.25mm (180g/m²) – 0.35mm (350g/m²)
Auto Sheet Capacity: Up to 250 sheet auto-sheet feeder
Media alignment: Slide adjustment with self centring guide

Cutting control

Speed: Cuts at up to 960mm second
Mounting tools: Single tool holder supports Cutting Blade (30°, 45° or 60°) for range of media types and also calibration pen for auto-calibration
Registration System: Vision3 – High resolution CCD vision system reads the registration marks on the media
Auto job recognition: Instant cut file retrieval, supported through QR code job recognition in conjunction with ColorCut Pro 3

Supplied Software: ColorCut Pro 3 with plug in support for Adobe Illustrator and CorelDRAW
