520 Crease Up/Down, Linear Perf
520 Crease Up/Down, Linear Perf
The 520 is an affordable tabletop manual feed creaser that delivers professional results comparable to more expensive models, all at a fraction of the cost.
Description
Additional Information
Size Chart
Infeed size: 140*210-520*900mm
Paper weight: 100-350gsm (350-500gsm as option)
Paper type: Chrome, laminated,UV coated etc
Crease width: 1.0mm (1.4mm/2.0mm as option)
Crease: Up to 32 times in one pass (Without F52)
Accuracy: ±0.2mm
Feeding type: Manual Feeding (C52 Auto Feeding (Aeolus52+H52
Control Panel: Keyboard and LCD screen
Progressive: Yes
Book cover mode: Yes
Fold mechanism: Linear perforate blade (12/24 TPI)
Power: Either 220V Or 110V ,50Hz/60Hz
