FB1175 digital flatbed cutter

The NEW flagship ColorCut FB1175 incorporates a B1+ cutting table for large format sheet cutting with the very latest in advanced high speed servo motors for accurate, fast and productive cutting.


Additional Information

Size Chart

Cut area:
Format/size: B1+ (4 x SRA3) / US ARCH E1 (4 x Tabloid Extra)
Maximum media area: 800mm x 1100mm
Effective contour cutting area: 750mm x 1095mm
Stand: Included
Media hold-down method: 1000W vacuum suction
Acoustic Muffler / Silencer: included

Cutting control:
Cutting carriage: Dual Tool Cutting Carriage, 2 independently operated Tool positions
Cutting force: Too1 (Cut) up to 1,200gf (1Kg) – Tool2 (Crease) up to 1,500gf (1.5Kg)
Max cutting depth: Paper/card up to 1000micron/800gsm, Max. depth 1.2mm (low density substrate ie. rice paper / airboard).
Max speed:* High Quality: 750mm/s. Standard Mode: 960mm/s. Fast Mode: 1,200mm/s
Typical cut accuracy: +/- 125 μ
Mountable tools: 3 tools supplied as standard for either tool position: Blade holder, creasing tool & pen tool

Software connectivity
ColorCut Pro – Production Studio: Windows 10 Pro x64 bit, 4 GB of RAM. Recommended Resolution: 1280×960 or higher.. Wi-Fi for Live Video (Wi-Fi Dongle inc. with cutter). 1 x USB or 1 x Ethernet.

Registration control:
Registration system: Advanced 8th generation ARMS (Automatic Registration Mark System), Uses hi-res CCD camera system to read QR codes for instant job retrieval, also accurately reads registration marks, corrects linear, scale, skew and rotational/angular positional differences adapting the the cut file as required.

Weight: 100kg unpacked.
Max’ dimensions: 1550 x 1350 x 1010mm
