SC6500 Auto sheet cutter/creaser

The New SC6500 combines high output with ultra-low energy consumption, in a compact format, capable of processing jobs at up to 1060mm/sec.


Additional Information

Size Chart

Media handling:
A4 (210 x 297mm), A3 (297 × 420mm), SRA3 (330 × 485mm), A3+ (320 × 480mm) and custom sizes

Custom sized media:
Media width (min-max): 180mm x 340mm / Media length (min-max): 279mm x 710mm

Job recognition:
Advanced QR code technology for instant file recognition and registration
Stand: included
Media storage: included
Media thickness: 140 micron (0.14mm ) – 350 micron (0.35mm)
Auto-sheet capacity: 1,000 sheets


Mountable tools: dual tool functionality – 4 tools supplied as standard: Blade holder, dual creasing tool & pen calibration tool
Force/pressure: up to 750g delivered in 190 steps programmable through Intec ColorCut Pro cutting software
Maximum speed: up to 1060mm/second


Registration system: Vision3 – High resolution CCD vision system reads the registration marks on the media, comparing position with original digital file. Automatically adjusting cut lines to correct any scale or skew positional differences
Cut position accuracy: +/- 100 micron
Auto job recognition: Instant cut file retrieval, supported through QR code job recognition in conjunction with ColorCut Pro 5 software (supplied)

Power supply: 100-240V 50/60Hz, 100W Avg. (320W peak)
Approvals: Complies with CE and RoHs directive


Weight: 136kg
Dimensions: when in use – 820 x 1300 x 1230mm (32.3 x 51 x 48.43 inches)
Varied or mixed job recognition: Y
