LPSC33
LPSC33
Description
Additional Information
Size Chart
Film: PET ,BOPP, Nylon, Softtouch, Laser
Film thickness: 25-125um
Max Roll dia.: 125mm
Film width: 190-330mm
Film holder width: Auto set
Heat roller pressure: Manual set
Slitter qty: 2
Max multi cut pc qty: 5
Infeed size: 180*180mm-320*900mm (W*L) (Lami Mode)
180*180mm-320*500mm (W*L) (Pouch Mode)
(Length more than 650mm request optional hardware)
Max Outfeed size: 320*894mm (W*L) (Lami Mode)
326*510mm (W*L) (Pouch Mode)
Min Outfeed size: 104*120mm (W*L) (Lami Mode)
186*186mm (W*L) (Pouch Mode)
Paper weight: 100-300gsm (Depends on film thickness)
Loading capacity: 70mm
Speed:0.5-2m/min
Accuracy:+/-0.4mm
Skew adjustment:Manual
Warmup time:5-15mm
Memory:20 jobs
Voltage:220V/110V 50-60HZ
