Multi Functional Booklet

Two bin feed, Crease, Cross/ Bi/Strick perf Stitch, Fold, Trim


Additional Information

Size Chart

Infeed size: 148.5*210-330*480mm
Output size: 148.5*80-330*240mm (Saddle stitch)
Output size: 268*112-330*247mm (Side stitch)
Loading capacity: Top 100mm and Bottom 350mm
Double feed detection: Ultrasonic Standard
Crease bar: 1.0  Standard / 0.6 1.0 1.2 1.4 option.
Progressive: Standard
End mark detect: Standard
Side blower / Tail blower: Standard
Option: Cross perforater, Linear perforater, Linear partial perforater, barcode reader
Stitching thickness: 2-25 pcs of 80gsm paper
Consumable: Steel Wire
Accuracy: +/-0.5mm
Side/back guide: Automatical adjustment
Fold roller gap: Automatical adjustment
Operation Display: Touch Screen
Side jog and Back Jog: Yes
Output conveyor: Standard
Stitch head qty: 2 (Deluxe latest new heads for digital)
Cutting capacity: 48 pc of 80gsm + 2 pcs of 128gsm cover
Cutting strip width: 2-20mm
